TJK436F000-U
TJK 3-POLE 400-AMP FRAME ONLY
Specifications
| part_number | TJK436F000-U |
| product_type | Molded Case Circuit Breaker |
| manufacturer | Schneider Electric |
| series | TJK |
| frame_size | 400 Amp |
| rated_current | 400 Amps |
| interrupting_rating | 65 kA at 480V AC |
| number_of_poles | 3 |
| voltage_rating | 600V AC |
| mounting_type | Panel |
| trip_unit_type | Fixed Thermal Magnetic |
| frequency | 50/60 Hz |
| terminal_type | Line and Load Lugs |
| approvals | UL Listed, CSA Certified |
| application | Power Distribution |
| dimensions_mm | 241 x 140 x 103 |
| operating_temperature_range | -25°C to +50°C |
| environmental_rating | NEMA 1 |
| status | Active |
