TED124030WL-U
GE TED124030WL Molded Case Circuit Breaker, 30A, 480V AC, 250V DC, 2 Poles
This content will be shared across all product pages.
Specifications
| part_number | TED124030WL-U |
| manufacturer | Eaton |
| product_type | Molded Case Circuit Breaker |
| family | Series C |
| number_of_poles | 2 |
| amperage_rating | 30A |
| voltage_rating | 240V AC |
| interrupting_rating | 65 kAIC @ 240V AC |
| mounting_type | Bolt-On |
| trip_unit | Thermal Magnetic |
| frame_type | TED |
| frequency_rating | 50/60 Hz |
| phase | 1 |
| wire_range | 14-8 AWG Cu/Al |
| certifications | UL Listed, CSA Certified |
| dimensions | 6.3 in x 3 in x 3.38 in |
| weight | 3.6 lbs |
| terminals | Line and Load |
| wire_connection | Lug |
| enclosure | Open |
| application | Panelboards, Switchboards, OEM |
| color | Black |
| operating_temperature | -20°C to 40°C |
