RTE-P11-120VAC-U
ANALOG TIMER RTE SERIES 2 FORM C - DPDT 10 AMP CONTACT PIN TERMINAL STYLE ON-DELAY/INTERVAL 0.1 SEC - 10 MINUTE RANGE 120 VAC INPUT
Specifications
| part_number | RTE-P11-120VAC-U |
| product_type | Electromechanical Relay |
| coil_voltage | 120 VAC |
| contact_configuration | SPDT |
| contact_rating | 10A at 250VAC / 10A at 30VDC |
| mounting_type | Plug-in |
| coil_power | 1.2 VA |
| terminal_type | Plug-in (Socket) |
| dimensions_mm | 29 x 12.7 x 25 |
| operating_temperature | -40C to +70C |
| status_indicator | None |
| manufacturer | IDEC |
| country_of_origin | Japan |
| certifications | UL, CSA, CE |
| typical_applications | Industrial Control, Automation |
| housing_material | Plastic |
| insulation_resistance | 1000 MΩ min (500VDC) |
| weight_g | 25 |
