QBP32225TP
Siemens 225A 3P 240V QB Breaker
Specifications
| part_number | QBP32225TP |
| manufacturer | Siemens |
| product_type | Circuit Breaker |
| series | QP |
| number_of_poles | 3 |
| amperage_rating | 225 |
| voltage_rating | 240 |
| interrupting_rating | 22 kAIC |
| mounting_type | Plug-In |
| trip_type | Thermal Magnetic |
| frequency_rating | 60 Hz |
| phase | 3 |
| wire_size | 4-300 kcmil Al/Cu |
| dimensions | 8.7 x 4.5 x 4.4 inches |
| unit_weight | 9.5 lbs |
| certifications | UL Listed |
| application | Panelboards, Loadcenters |
