HLL36125
125A 3P 600V L-Frame Breaker
Specifications
| part_number | HLL36125 |
| manufacturer | Eaton |
| product_name | Circuit Breaker |
| type | Molded Case Circuit Breaker |
| number_of_poles | 3 |
| amperage_rating | 125A |
| voltage_rating | 600V AC |
| interrupting_rating | 35 kAIC |
| trip_unit | Thermal Magnetic |
| mounting_type | Bolt-On |
| frame_type | L-Frame |
| frequency | 50/60 Hz |
| phase | 3 |
| approvals | UL Listed, CSA Certified |
| dimensions | 6.61 in x 4.13 in x 3.38 in |
| weight | 6.2 lbs |
| wire_size | 4 AWG-300 kcmil (Cu/Al) |
| application | Panelboards, Switchboards, Motor Control Centers |
| environmental_rating | NEMA 1 |
| country_of_origin | USA |
