HLL36060U43XEN
PowerPact L‑frame Molded Case Circuit Breaker
Specifications
| part_number | HLL36060U43XEN |
| product_type | Molded Case Circuit Breaker |
| manufacturer | Eaton |
| amperage_rating | 60A |
| number_of_poles | 3 |
| voltage_rating | 600V AC |
| interrupting_rating | 65kA@480V AC |
| trip_type | Thermal Magnetic |
| frame_type | H-Frame |
| mounting | Unit Mount |
| frequency_rating | 50/60 Hz |
| protection | Standard |
| lug_type | Line and Load Lugs Included |
| wire_range | 14-3/0 AWG Cu/Al |
| certifications | UL Listed, CSA Certified |
| application | Panelboards, Switchboards, Power Distribution |
| environment | Indoor |
| special_features | HACR Rated |
| series | Series C |
| dimensions | 10.00 x 4.16 x 3.38 inches |
| weight | 8.0 lbs |
| color | Black |
| operating_temperature | -40°C to 70°C |
| country_of_origin | USA |
