FXD63A250-U
SIE: 3PH 3P 600V 250A 35kA@480V
Specifications
| part_number | FXD63A250-U |
| product_type | Molded Case Circuit Breaker |
| brand | Schneider Electric |
| series | PowerPact FXD |
| frame_size | 250 Amps |
| current_rating | 250 Amps |
| interrupting_rating | 35 kA @ 480V AC |
| number_of_poles | 3 |
| voltage_rating | 600V AC |
| mounting_type | Unit Mount |
| trip_unit_type | Thermal Magnetic |
| terminal_type | Line and Load Lugs |
| frequency | 50/60 Hz |
| phase | 3 Phase |
| operating_temperature | -25°C to 70°C |
| wire_size | 3 AWG to 300 kcmil |
| compliance | UL Listed, CSA Certified |
