EGB34030
Mini circuit breaker, E-Frame, 30A, 3 pole, 480Y/277 VAC, 65 kA max, bolt on
Specifications
| part_number | EGB34030 |
| manufacturer | Siemens |
| product_type | Circuit Breaker |
| series | EGB |
| amperage | 30 |
| poles | 3 |
| voltage_rating | 480Y/277 VAC |
| interrupting_rating | 35 kAIC |
| mounting_type | Bolt-On |
| frequency | 50/60 Hz |
| trip_type | Thermal Magnetic |
| phase | 3 |
| lug_type | Cu/Al |
| wire_range | 14-6 AWG |
| terminal_connections | Line and Load |
| UL_listed | Yes |
| dimensions_inches | 5.50 x 3.00 x 3.38 |
| weight_lbs | 3.25 |
| application | Panelboards, Switchboards |
| RoHS_compliant | Yes |
